Rad Power RadWagon 5
Heavy-duty longtail cargo e-bike with a 750W motor (90Nm torque), 375 lb payload capacity, torque sensing, and UL 2849 Safe Shield battery.
PROS & HIGHLIGHTS
- 90Nm high-torque motor effortlessly handles steep hills under full load
- Updated 20-inch wheels lower center of gravity for maximum stability
- Safe Shield potting technology provides industry-leading UL thermal safety
- Tektro hydraulic disc brakes offer strong, reliable stopping power
CONS & CONSIDERATIONS
- Heavy 86 lb overall weight requires effort to maneuver off the bike
- 45mm front suspension fork travel is modest for rough gravel roads
Field Review & Road Test Video
Executive Summary & Heavy Payload Verdict
The Rad Power RadWagon 5 marks a major engineering overhaul for North America’s most recognizable longtail cargo e-bike. Upgraded with a 750W rear hub motor delivering 90Nm of torque, hydraulic disc brakes, and a bottom-bracket torque sensor, the RadWagon 5 transforms family hauling and grocery runs into a smooth, effortless experience.
Motor Torque & Grade Climbing Under Load
Equipped with a custom-tuned 750W geared hub motor pushing a massive 90Nm of torque, the RadWagon 5 easily pulls a full 375 lb maximum payload up 10% grade inclines. The addition of a torque sensor replaces the delayed acceleration of previous cadence-based generations, delivering instant, proportional power assistance matching your pedal force.
Battery Telemetry & Thermal Safety Standard
Power is supplied by Rad Power’s 48V 15Ah (720Wh) Safe Shield External Battery. Built with thermal containment potting around individual cells, the battery pack holds dual UL 2271 and UL 2849 safety certifications. In our loaded range testing carrying 120 lbs of cargo on the rear rack, the bike achieved 31.4 miles in PAS Level 3 and 52.8 miles in Eco mode.
Frame Geometry, Brakes & Passenger Features
The updated chassis features a 2.6-inch lower standover height (21 inches) and smaller 20×3.3-inch tires, lowering the center of gravity to improve balance with heavy rear loads. Tektro hydraulic disc brakes clamping 180mm rotors bring the 86 lb bike to a controlled stop from 20 MPH in 15.1 feet. Integrated rear turn signals and bright LED running lights come standard for night commuting safety.
